The stainless steel chassis of the Royal Karat originates from Slovenia, and the basic structure is also used by the Take Off company. The Karat wing is produced by the same supplier.

Royal Karat
Empty weight: 190 kg
Wing span: 10.60 m
Wing area: 13.8 sq.m
Fuel capacity: 60 lt
Certification: Vz
Engine: Rotax 582, 64 hp
MAUW: 400 kg
Seats: 2
Max speed: 130 kph
Cruise speed: 85 kph
Minimum speed: 50 kph
Climb rate: 4.5 m/s
Fuel consumption: 11 lt/hr
Price (1998): 38 800 DM

The Dynamic wings were designed by DTA and Jean Marc Rousellet and are manufactured exclusively for DTA by the Ellipse company in France.

The Dynamic 503 16 is based on a stainless steel spaceframe. This trike has an articulated monopole under the seat for easy rigging of the wing, which is a Dynamic 16 produced by llipse on the company’s behalf.

The Dynamic 582 Feeling is a higher performance version of the 16. The same structure is fitted with a Rotax 582, a fairing and smaller Dynamic 15 wing. A four stroke 912 is an option.

They feature individual composite seas.

Dynamic 503 16
Empty weight: 152 kg
Wing span: 10.30 m
Wing area: 14.50 sq.m
Fuel capacity: 50 lt
Engine: Rotax 503, 50 hp
MAUW: 400 kg
Seats: 2
Max speed: 115 kph
Cruise speed: 80 kph
Minimum speed: 50 kph
Climb rate: 3.6 m/s
Fuel consumption: 11.5 lt/hr
Price (1998): 93 540 F

Dynamic 582 Feeling
Empty weight: 180 kg
Wing span: 9.90 m
Wing area: 15 sq.m
Fuel capacity: 50 lt
Engine: Rotax 582, 64 hp
MAUW: 400 kg
Seats: 2
Max speed: 136 kph
Cruise speed: 100 kph
Minimum speed: 56 kph
Climb rate: 4.5 m/s
Fuel consumption: 11 lt/hr
Price (1998): 28 000 Fttc

Dynamic 15/430
Max take-off weight: 430 kg / 946 lbs
Maximum speed: 86 mph
Minimum speed: 32 mph
Double surface: Yes

Dynamic 16
Max take-off weight: 400 kg / 880 lbs
Maximum speed: 75 mph
Minimum speed: 31 mph
Double surface: Yes

Dynamic 450
Max take-off weight: 450 kg / 990 lbs
Maximum speed: 85 mph
Minimum speed: 31 mph
Double surface: Yes

Available with the Rotax 503 and 582 as well as the Rotax 912 and 912S, this machine gives you performance capabilities and robust strength not normally found in an affordable and easy to inspect/maintain aircraft. With the available option of the Voyageur-II’s cantilever mast, this machine can be flown with no front strut.

Stall: 27 kt / 31 mph / 50 kmh
Cruise: 54 kt / 62 mph / 100 kmh
VNE: 86 kt / 99 mph / 160 kmh
Climb Ratio: 1000 ft/min / 5 m/s
Glide Ratio: 8

The Voyageur 912 XP15 is a large trike with a topless wing, designed for aerial work or long rallies. It features individual composite seats.

The basic design is an aluminum sandwich with extra reinforcing structure. It also has a safety cable running through the sandwich. The sandwich is riveted and also bonded with aeronautical Araldite structural epoxy.
The Voyageur 912 was created for this purpose and became the first trike to be fitted with the 4-stroke 80HP Rotax 912 engine.
With the available option of the Voyageur-II’s cantilever mast, this machine can be flown with no front strut, just like its big brother.
The Voyageur II trike features a cantilever mast that is structurally strong enough to eliminate the need for the standard front tube. The basic design is an aluminum sandwich with extra reinforcing structure. It also has a safety cable running through the sandwich. The sandwich is riveted and also bonded with aeronautical Araldite structural epoxy.
The Voyageur trike utilizes only 4130 chromoly steel, a primarily stainless steel frame and aircraft grade aluminium, and is made in France.
Features that come standard on the Voyageur II include:
Full front and rear shock absorbers (rear gas shocks)
3-wheel brakes with parking brake
Cruise throttle
Large aviation tires
Padded seat covers
Rear seat head rest
Side luggage bags
Large capacity fuel tank with fuel level gauge
Instrument panel
RPM gauge, hourmeter, water temp gauge
Full electrical system
Assembled pitot system

Voyageur II / Dynamic 16
Engine: Rotax 582

Voyageur II / Dynamic 15/430
Engine: Rotax 582
Engine: Rotax 912 UL
Engine: Rotax 912S ULFR

Voyageur II / Dynamic 450
Engine: Rotax 582
Empty Weight: 407 lbs
Gross Weight: 992 lbs
Useful load (582): 585 lbs
Useful load (912/S): 532 lbs
Wingspan: 33’ 5” (10.2 m)
Wing Area: 167 sq. ft (15.5 sq.m)
Length: 9’ 9” inches
Height: 12’ 5”
Fuel Capacity: 18 gallons
Cruise Speed: 56 mph
Vne: 90 mph
Rate of Climb: 700 fpm
Takeoff distance at gross weight: 262 feet
Takeoff distance over a 50′ obstacle:n 590 feet
Landing distance at gross weight: 165 feet
Landing distance over a 50′ obstacle: 560 feet

Voyageur 912 XP15
Empty weight: 225 kg
Wing span: 10 m
Wing area: 15.50 sq.m
Fuel capacity: 80 lt
Engine: Rotax 912, 80 hp
MAUW: 450 kg
Seats: 2
Max speed: 135 kph
Cruise speed: 100 kph
Minimum speed: 63 kph
Climb rate: 5 m/s
Fuel consumption: 10 lt/hr
Price (1998): 220 950 Fttc

Engine: Rotax 912S ULFR
Empty Weight: 460 lbs
