LWD Mis

During 1947 LWD commenced development of a light transport for use as a feederliner. Named Mis, it is a high wing monoplane of composite wood and metal construction.

The wing is wood, and the fuselage a metal, basically rectangular structure, with a rounded decking on the upper and lower surfaces.

Other features are a single fin and rudder and a fixed tricycle undercarriage, the main wheels strutted to the fuselage and engine nacelles.

The Mis accommodates a crew of two and eight passengers.

Engines: 2 x Argus As 10, 240 hp
Wingspan: 16 m / 52 ft 6 in
Length: 12 m / 39 ft 4.5 in
Wing area: 40 sq.m / 430 sq.ft
Empty weight: 2000 kg / 4410 lb
Loaded weight: 3000 kg / 6615 lb
Cruise 60%: 220 kph / 137 mph
Crew: 2
Passengers: 8

Alcor C-6-1 Junior

Alcor C-6-1 NX15544

The 1937 Alcor C-6-1 Junior eight-pace cabin monoplane, with retracting undercarriage, registered NX15544, crashed in final testing.

Only the one was built. Often incorrectly referred to as “Lockheed Alcor.”

Engines: 2 x 150hp Menasco C-6
Wingspan: 49’0″
Length: 31’8″
Useful load: 2059 lb
Max speed: 211 mph
Cruise: 190 mph
Seats: 8
