The Zlin 22 appeared in 1947 as a two-seat trainer, powered by a Zlin Persy III engine of 57 hp.

When production of the Persy engine was discontinued, the Zlin 22 was re-engined with a 75 hp Praga D as the Zlin 22D, and a 105 hp Walter Minor 4-III as the three seat Zlin 22M.

Two prototypes of the Zlin 122 version were produced. Three/four seat, they were powered by a 105 hp Zlin Toma 4 engine.

Zlin 22
Engine: Zlin Persy III, 57 hp
Wingspan: 34 ft 9 in
Length: 23 ft 9 in
Height: 6 ft 5 in
Wing area: 157.7 sq,ft
Seats: 2

Zlin 22D
Engine: Praga D, 75 hp
Wingspan: 34 ft 9 in / 10.6 m
Length: 23 ft 9 in / 7.25 m
Height: 6 ft 5 in
Wing area: 157.7 sq,ft / 14.6 sq.m
Empty weight: 804 lb / 365.0 kg
Loaded weight: 1399 lb
Wing load: 8.2 lb/sq.ft / 40.0 kg/sq.m
Max speed: 112 mph / 95 kts / 176 km/h
Cruise: 100 mph / 84 kts / 155 km/h
Service ceiling: 13,780 ft / 4200 m
Range: 435 mi / 270 nm / 500 km
Seats: 2

Zlin 22M
Engine: Walter Minor 4-III, 105 hp
Wingspan: 34 ft 9 in
Length: 23 ft 9 in
Height: 6 ft 5 in
Wing area: 157.7 sq,ft
Empty weight: 926 lb
Loaded weight: 1588 lb
Max speed: 133.5 mph
Cruise: 121 mph
Ceiling: 18,040 ft
Range: 620 mi
Seats: 3

Zlin 122
Engine: Zlin Toma 4, 105 hp
Seats: 3-4
