In 1960 the GY 80 Horizon 180hp tourer appeared. This single engined machine won the Cannes International Grand Prix in 1966, beating the highest performance twins of the time by covering in 23 h of flight a distance of 3443 mile at 152 mph average (5540 km at 245 kph).
The Horizon had a run of 270 in France, Aerospatiale having ac¬quired the production licence, but its succes¬sor the GY 100 in 1969 was never produced commercially.
One of SOCATA’s first products was the four-seat GY.80 Horizon under licence. The type first flew in July 1960 and is of all-metal construction with standard low-wing monoplane configuration and full span Fowler-type flaps and Frise-type ailerons. All three tricycle landing gear units retract to the rear and leave their wheels partially exposed.
The GY-80 was built in four basic versions. Standard versions have 160 hp or 180 hp engine and fixed pitch propeller. A constant speed propeller was available optionally with either engine.
The first 75 aircraft have the 119-kW (160 hp) O-320-D engine driving a fixed-pitch two-blade wooden propeller, later aircraft having more power and a constant speed three-blade propeller.
Production of 260 aircraft last to 1969.
GY.80-150
GY.80-180 Horizon
Engine: l x Avco Lycoming O-360-A, 134kW (180hp).
Span: 9.70m (31 ft 9.75in).
Length: 6.64m (21ft9.5in).
Max T/O weight: 1150kg (2,535lb).
Max speed: 155 mph at sea level.
Operational range: 777 miles.
SOCATA GY-80 Horizon
Engine: Lycoming O-320-D, 160 hp
Prop: fixed pitch
Wing span: 31 ft 10 in / 9.70 m
Length: 21 ft 9.5 in / 6.64 m
Cabin length: 7 ft 2.5 in / 2.20 m
Cabin width: 3 ft 7 in / 1.10 m
Cabin height: 4 ft 1 in / 1.25 m
Empty weight equipped: 1334 lb / 605 kg
MTOW: 2315 lb / 1050 kg
Max cruise 75% 8200ft / 2500m: 124 kt / 143 mph / 230 kph
ROC SL: 660 fpm / 201 m/min
Service ceiling: 13,450 ft / 4100 m
Range 44 ImpGal / 200 lt fuel: 512 nm / 590 mi / 950 km
Seats: 4
Baggage capacity: 88 lb / 40 kg
SOCATA GY-80 Horizon
Engine: Lycoming O-360-A, 180 hp
Prop: fixed pitch
Wing span: 31 ft 10 in / 9.70 m
Length: 21 ft 9.5 in / 6.64 m
Cabin length: 7 ft 2.5 in / 2.20 m
Cabin width: 3 ft 7 in / 1.10 m
Cabin height: 4 ft 1 in / 1.25 m
Empty weight equipped: 1360 lb / 617 kg
MTOW: 2535 lb / 1150 kg
Max cruise 75% 8200ft / 2500m: 130 kt / 150 mph / 240 kph
ROC SL: 850 fpm / 258 m/min
Service ceiling: 14,800 ft / 4500 m
Range 44 ImpGal / 200 lt fuel: 674 nm / 777 mi / 1250 km
Seats: 4
Baggage capacity: 88 lb / 40 kg
