IAR IAR-827

IAR-827A

The IAR-827 made its first appearance in the West at the 1981 Paris Air Show, having been in production for more than a year after first flying in mid-1976, primarily for domestic heavy-duty agricultural needs. The IAR-827 is an enlarged and developed version of the IAR-826 with more powerful engines and increased payload.

Production was transferred to Brasov from Bucharest.

Testing indicated that the IAR-827 with a 400 hp Lycoming IO-720-DA1B was under-powered, and the IAR-827A evolved with a PZL-3S of 600 hp, seating two, side-by-side.

Construction of the forward fuselage is of welded chrome molybdenum steel tube, covered with light alloy panels, and the rear fuselage is a light alloy monocoque; the wing has two electrically-operated all-metal single-slotted flaps, and plain slotted ailerons. Automatic trim tabs are fitted in both ailerons and the port elevator, and a manually controlled tab is fitted in the starboard elevator.

The hopper can carry up to 2200 lb / 1000 kg, but normal operating loads are 1764 lb / 800 kg dry or 264 Imp.Gal / 1200 ltf liquids.

Engine: PZL-35

Engine: Lycoming IO-720, 400 hp
Wingspan: 47 ft 6.75 in / 14.50 m
Length: 33 ft 9.5 in / 10.30 m
Empty weight: 2800 lb / 1270 kg
Chemical payload-2hr mission: 1807 lb / 820 kg
Max payload: 1984+ lb / 900+ kg
MTOW: 5202 lb / 2360 kg
Cruise speed: 87 kt / 112 mph / 180 kph
ROC: 689 fpm / 210 m/min
Operating ceiling: 8200 ft / 2500 m
Service ceiling: 9850 ft / 3000 m
Max range at 3306 lb / 1500 AUW: 323 nm / 372 mi / 600 km
Seats: 1

IAR-827A
Engine: PZL-3S, 600 hp
Cruise 75%: 412 hp
Econ cruise: 60%: 330 hp
Prop: 4 blade VP CS 8 ft 7 in / 2.62 m
Max speed: 143 mph / 230 kph
Working speed: 92-112 mph / 150-180 kph
Stall: 71 mph / 115 kph
ROC: 590 fpm / 3 m/sec
Service ceiling: 13,120 ft / 4000 m
Take off run: 656 ft / 200 m
Landing run: 492 ft / 150 m
Working range: 217 mi / 350 km
Empty weight: 3638 lb / 1650 kg
Norm payload: 1764 lb / 800 kg
MTOW: 6173 lb / 2800 kg
Wingspan: 45 ft 11 in / 14.00 m
Length: 28 ft 2.5 in / 8.60 m
Height: 12 ft 3.5 in / 3.75 m
Wing area: 322.9 sq.ft / 30.0 sq.m
Aspect ratio: 6.6
Dihedral: 6 deg constant
Seats: 2

IAR-827A
