Designed as an armed reconnaissance aircraft incorporating the wings, fuselage and tail unit of the Ha 139. Powered by four BMW 132H engines.
Few built and used as transports by the Luftwaffe.
Ha 142 V2 received factory code PC+BC and was used for transport duties by the Aufklärunsgruppe Ob.d.L.in France during the autumn of 1940 where re-coded T5-CH.
Engines: 4 x BMW 132H, 735kW
Take-Off Weight: 16700 kg / 36817 lb
Empty Weight: 6390 kg / 14088 lb
Wingspan: 29.5 m / 96 ft 9 in
Length: 19.7 m / 64 ft 8 in
Wing Area: 130.0 sq.m / 1399.31 sq ft
Max. Speed: 400 km/h / 249 mph
Cruise Speed: 350 km/h / 217 mph
Ceiling: 6800 m / 22300 ft
Range W/Max.Fuel: 4400 km / 2734 miles
Crew: 4-5
